Description
NOTE: this is a pre-order at limited early supporter prices. I will aim to ship all pre-orders out no later than 15 DEC 2026 and keep you updated if anything changes
PART OF THE TELEVOYANCE SD EURORACK VIDEO SYSTEM
DEMO VIDEO COMING SOON
- the module is 22HP wide and 22mm deep
- it draws 130mA@+12V and 10mA@-12V
SEER is modified for eurorack from an existing CVBS REVERSING CAR MONITOR
The screen is 110mm diagonally (4.3inchs), 96mm wide and 55mm high
there is RCA VIDEO_IN which is sent to the display and also buffered and send out on 2x RCA VIDEO_THRU
it also has three PUSH BUTTONS (UP, MENU, DOWN) to access the menu
From this menu you can set the displays BRIGHTNESS, CONTRAST, SATURATION, TINT, LANGUAGE, MODE (ASPECT RATIO), RESET
