Description
NOTE: this is a pre-order at limited early supporter prices. I will aim to ship all pre-orders out no later than 1 DEC 2026 and keep you updated if anything changes
PART OF THE TELEVOYANCE SD EURORACK VIDEO SYSTEM
DEMO VIDEO COMING SOON
- EMBER_MINI_PSU can be powered with 9-20VDC 2.1MM BARREL INPUT
- and outputs -12VDC,+12VDC @ 6000mA over 6x EURORACK 10P IDC HEADER
- The board is 80x42mm in size and no more than 14mm high
The DC POWER INPUT can be chained to other compatible PSUs through two JST_VH_3PIN connectors
NOTE: these connectors are for powering multiple PSUs with a single DC SUPPLY only – never connect multiple DC SUPPLIES together!
For each power output stage an LED and TEST POINT is on the board for troubleshooting
Included with this PSU is an optional front_panel + 2x panel_mounts allowing EMBER to be rack mounted as a 4HP module:
EMBER_MINI_PSU (and our larger AETHER_PSU pictured) can be combined with our ALTAR_ENCLOSURES where they will come mounted to bottom of enclosure and connected to an integrated external power plug/switch:
